Kitagawa BRT-12 Power Chuck
High Precican, Ultra Large Through-hole, High Speed Power Chuck.
Manufactured from high grade alloy steel. Three jaw wedge style power chucks deliver up to 20% more speed, gripping force and bore size when compared to conventional chucks.
High standard gripping accuracy of 0.01mm or less with formed jaws gripping a test bar.
Interchangeable with BT212 & BBT212.
Low centrifugal force at high speeds.
Key features
Suitable for workpiece transfer with sub spindle
Accuration: Hydraulic
Matching Cylinder: SS2110K
Matching Hard Jaw: HB12N1
Most Common Soft Jaw: 8045 & 8529
Tnut & TnutPlus: TN1230BB212 & TN12PLUS
Recommended Grease:Kitagawa Grease Pro White
Technical specificiations
Supplied with plain back mount and blank drawnut, machinable up to MXX × 2P
Please complete the spindle datasheet below and submit it with your order ensure mounting compatibility with current set up
.webp)
Ordering information
Sign in to your account or contact Dimac to arrange Online Ordering access before placing an order request. Add products to your order and submit your order request online.
You'll receive an automatic order receipt by email, but this confirms your order request only and does not confirm product availability, delivery costs or acceptance of your order.
Dimac will then review your order request and issue an official Order Confirmation confirming product availability, delivery costs and any prepayment requirements.
Orders are only accepted once this confirmation has been issued. Dimac primarily ships within Australia and New Zealand.
